ATC SCM11

SCM11

Overview

• New ATC designed and built 25mm soft dome HF unit with precision alloy wave guide.
• Precision undercut bass pole.
• “CLD” driver technology with 45mm integral soft dome.
• In-house, hand-wound precision flat wire coil.
• Massive optimised motor assembly.
• Flat impedance curve allowing easy load for amplifiers.
• 6 year warranty.

Drivers: HF ATC 25mm Neodymium soft dome, Mid/LF ATC 150mm CLD
Matched Response: ±0.5dB
Frequency Response (-6dB): 56Hz-22kHz
Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
Sensitivity: 85dB @ 1W @ 1metre
Max SPL: 108dB
Recommended Power Amplifier: 75 to 300 Watts
Nominal Impedance: 8 Ohm
Crossover Frequency: 2.2kHz
Connectors : Binding Posts/4mm Plugs, bi-wire
Cabinet Dimensions (HxWxD): 381x232x236mm (grill adds 28mm depth)
Weight: 10.9kg

What Hi-Fi October 2014 “ATC has raised the bar it set itself. This isn’t just a step up – it’s a running leap.”

What Hi-Fi October 2013“ATC has struck gold again. These are the most talented standmounters anywhere near this price.”

Hi-Fi Wigwam – March 2014

Stereomojo – March 2014

HiFi i Muzyka – January 2014

Hi-Fi Pig – March 2015

SCM11 Review, Financial Times, Jonathan Margolis, September 2015

SCM11 Review, HIFICRITIC, March 2016

Entry Series Manual

Brochure (individual A4 page)

Entry Series Brochure

Loudspeaker ‘Footprint’ Drawing
