The PAX Eos 100H is a compact, plug-in residential heat recovery ventilation unit designed to enhance indoor air quality and deliver up to 80% heat recovery efficiency.
The PAX Eos 100H is an advanced, decentralized ventilation unit engineered with built-in heat recovery to upgrade and reinforce natural or mechanical ventilation systems locally. Featuring a factory-fitted power plug, it offers an exceptionally straightforward retrofit installation that can service an entire floor level up to approximately 70-80 m².
Specifically developed for Nordic climates, the unit features a high-efficiency cross-counterflow heat exchanger that recovers up to 80% of heat from outgoing indoor air to preheat the fresh incoming air stream without mixing them. This continuous energy recovery minimizes heating losses and lowers household energy consumption.
For maximum winter comfort, the Eos 100H integrates an automatic electric preheater with a capacity of up to 375 W, ensuring that supply air delivered into the living space remains pleasantly warm even during sub-zero exterior temperatures.
Smart automation is at the core of the PAX Eos 100H. It features an integrated humidity sensor that automatically increases airflow during and after showers or bathing, returning to baseline ventilation once the room is dry. All operating speeds—30, 52, or 78 m³/h—can be effortlessly controlled via the included remote control.
With its compact dimensions (595 mm wide, 340 mm high, and 191 mm deep) and wall or ceiling mounting flexibility, the unit eliminates the need for extensive ductwork. Air intake and exhaust occur through short duct runs, significantly reducing installation complexity and eliminating condensation or leakage concerns within interior structures.
- Product Type: Heat recovery ventilation unit
- Model: Eos 100H
- Connection: Plug-in power cord
- Heat Recovery Efficiency: Up to 80% (75-80%)
- Maximum Air Flow: 78 m³/h
- Air Flow Speeds: 30 / 52 / 78 m³/h
- Preheater Capacity: Max 375 W
- Power Consumption: 3.5 – 25 W (excluding preheater)
- Sound Level: 18 – 35 dB(A) at 3m
- Ingress Protection Rating: IP24
- Motor Type: Electronically commutated (EC)
- Heat Exchanger Type: Cross / counterflow heat exchanger
- Sensors: Integrated humidity sensor
- Control: Remote control included
- Recommended Coverage: 70 – 80 m²
- Mounting: Wall or ceiling installation
